| Resolution |
OD Size (mm) |
Model No. |
View Area (mm) |
Construction |
LCD display mode |
Backlight Color |
Controller IC |
Interface |
LCD Voltage |
| 96×32 | 38.6×20.0×2.8 | ND-G9632AYAW-G | 34.6×12.0 | COG | STN/Y-G | None | ST7567 | SPI-4 | 8.0V |
| 128×32 | 70.5×30.0×4.0 | ND-G12832DDTLWW-G | 64.5×17.5 | COG | DFSTN-负显 | White | UC1601S | 8Bit | 8.0V |
| 128×32 | 70.5×30.0×4.0 | ND-G12832DFTLWW-G | 64.5×17.5 | COG | FSTN | White | UC1601S | 8Bit | 8.0V |
| 128×32 | 60.0×20.0×3.5 | ND-G12832FFILWW-G | 55.0×12.3 | COG | FSTN | White | ST7566R | 8Bit | 7.0V |
| 128×64 | 78.0×70.0×14.0 | ND-G12864AYILY | 62.0×44.0 | COG | STN-YG | Y-G | UCi0108 | 8Bit | 13.0V |
| 128×64 | 93.0×70.0×13.5 | ND-G12864BGILYW | 71.6×38.9 | COG | STN-G | Y-G | UCi0108 | 8Bit | 9.0V |
| 128×64 | 45.0×33.0×3.4 | ND-G1286404SGTWW-G | 40.0×22.0 | COG | STN/Gray | White | ST7567 | 8Bit, SPI-4 | 9.0V |
| 128×64 | 73.5×45.7×2.8 | ND-G12864035FM-G | 70.5×36.2 | COG | FSTN/TRANSMISSIVE | None | UC1701x | 8Bit | 9.5V |
| 128×64 | 73.5×45.7×6.0 | ND-G12864035FILW-G | 70.5×36.2 | COG | FSTN/TRANSFLECTIVE | White | UC1701x | 8Bit | 9.5V |
| 128×64 | 73.5×45.7×6.0 | ND-G12864035SULW-G | 70.5×36.2 | COG | STN/Blue/NEGATIVE | White | UC1701x | 8Bit | 9.5V |
| 128×64 | 56.6×36.0×2.9 | ND-G12864036YN-G | 53.6×29.0 | COG | STN/Y-G | None | ST7567 | 8Bit, SPI-4 | 9.4V |
